Ceramabond 865
- 品牌：AREMCO
- 发布日期： 2022-09-26
- 更新日期： 2023-09-25
产品详请
| 品牌 | AREMCO |
| 英文名称 | Ceramabond 865 Aluminum Nitride |
| 是否危险化学品 | 否 |
| 别名 | Ceramabond 865 Aluminum Nitride |
| 保质期 | 个月 |
| 是否进口 | 是 |
High temperature one-part aluminum nitride based adhesive. Perfect for probes and sensors. Excellent for thermal conductivity. Bonds and seals ceramics to ceramics and ceramics to metals in applications up to 3000°F (1650°C).
Ceramabond 865 exhibits a dielectric strength of 187 volts per mil, torque strength of 27 ft-lbs, and coefficient of thermal expansion of 1.5 in/in/°F.
The product must be step cured at 200°F (93°C), 350°F (177°C), and 500°F (260°C) for 2 hours at each temperature. Applied in a thin coat using a brush, spatula or dispenser. The clearance between mating parts at operating temperature should be 2-8 mils (50-200 microns). Blistering may occur if the glue line is too thick or heating too rapid.
Ceramabond 865 exhibits a dielectric strength of 187 volts per mil, torque strength of 27 ft-lbs, and coefficient of thermal expansion of 1.5 in/in/°F.
The product must be step cured at 200°F (93°C), 350°F (177°C), and 500°F (260°C) for 2 hours at each temperature. Applied in a thin coat using a brush, spatula or dispenser. The clearance between mating parts at operating temperature should be 2-8 mils (50-200 microns). Blistering may occur if the glue line is too thick or heating too rapid.
